Silicone Materials
Liquid silicone rubber products include liquid silicone rubber, fumed liquid silicone rubber, and precipitated liquid silicone rubber. Different grades can be selected according to customer requirements, including high transparency, high strength and low viscosity.
The products are categorized into three main types: liquid silicone rubber, fumed liquid silicone rubber, and precipitated liquid silicone rubber. Products with different characteristics such as high transparency, high strength and low viscosity can be selected.
| Product Model | Description | Viscosity (Pa.S) | Hardness (Shore A) | Density (g/cm³) | Tensile Strength (MPa) | Elongation (%) | Tear Strength (KN/m) | Linear Shrinkage Rate | Features |
|---|---|---|---|---|---|---|---|---|---|
| CL-6110 | Transparent | 4000 | 10 | 1.08 | 4.5 | 900 | 8 | 2.3 | High transparency, high strength |
| CL-6220 | Transparent | 5000 | 20 | 1.10 | 6.5 | 850 | 14 | 2.1 | High strength |
| CL-6320 | Transparent | 5000 | 20 | 1.10 | 5.5 | 800 | 12 | 2.1 | General-purpose fumed liquid silicone rubber |
| CL-6525 | Transparent | 800 | 25 | 1.08 | 4.5 | 400 | 12 | 2.0 | General-purpose precipitated liquid silicone rubber |
| CL-6610 | Transparent | 10 | 10 | 1.05 | 2.0 | 800 | 5 | 2.0 | Low viscosity |
Huinergy Silicone engineering team provides material selection recommendations and technical support based on your application requirements.
